Parameter | Specs |
|---|---|
Model No. | YF-B10-S |
Material | #304 Stainless Steel |
Connection | G1'' Male*Male |
Inner & Outer Dia | 24.38 / 32.9mm |
Operating Voltage | 3.5-24V DC |
Working Current | <15mA |
Liquid Temperature | <80°C |
Flow Rate | 2 - 50L/min |
Frequency Hz / K Factor | 10*Q-5 |
NPN Pulses | About 595P/L=1Liter Water |
Accuracy | +/-5% |
Max Pressure | 1.75MPa |
Cable Connector | PVC CABLE SM-3P 50cm |
Wiring | RED-VCC, YELLOW-SIGNAL, BLACK-GND |
